After you’ve designed a printed circuit board, your contract manufacturer will create reliable PCBs from your design. One of the most important documents that you will create for this process is the Gerber file, which is used to fabricate the raw circuit board. Therefore, your documentation must be complete and accurate.

To help you to be better prepared, here’s a look at how Gerber files are explained and how they’re used in the manufacturing of your circuit board. In this passage, we will provide you everything about the details about it. So please check and read the content we prepare for the more information.

If you want to order PCB product, please check and custom your order online.

What are the 7 tips of generate Gerber file?

1.      Knowing the role of Gerber file of PCB

Gerber file history can be traced back to the needs of the original vector photoplotters. In order to give the plotter its instructions, a Gerber file contained minimal plotter configuration information, and X/Y coordinates followed by a flash or drawing command and which aperture position to use. The Gerber data has increased in functionality over the year; it now includes additional configuration information as well as macro and aperture definitions.

The PCB manufacturing technology used today has come a long way over the past decades. Previously, vector photoplotters were used to create the tooling film used in the PCB manufacturing process.  There was only a minimal set of apertures available and designers had to be creative in restricting their flashes and lines to only the apertures that were available to them.

2.      Try to learn Gerber file format

RS274-D

The oldest format of Gerber file designed by Gerber Scientific. The file was represented in the numerical control (NC) format, and it was compatible with different photo plotters used in the 1970s. Due to several drawbacks of this format, manual input of d-codes, user interpretation, other types of Gerber files have been developed since.

RS274X

This Gerber file format has been used since 1998. This revised format of RS274-D utilizes an embedded format, unit and data information. The apertures defining the layers are embedded allowing for standard sizes and custom apertures. In addition, the RS274X format allows the designer to utilize film control, multiple layer structure for single layers, special polygon fill commands, polarity controls, and much more.

3.      Where to meet PCB in Gerber file?

So far, we have covered the essential details of PCBs are and their importance. Wne have also tried to explain in a nutshell the essence of Gerber files.  From the two definitions, it was prominent that Gerber files are the software sketches that are used to communicate information about the composition of circuit boards.  The two differ in that software applications handle Gerber files whereas PCBs mount electronic components.

4.      How to process missing board online?

Among other Gerber file pieces, the board outline is arguably one of the simplest ones. However, besides its simplicity, it is still essential to describe the board edge's real bounds to your manufacturer.

By issuing out such specifications, you ensure that there is excellent routing from the panel. The board outline should not be missing at all and must be present all the time. So, you need to ensure that you double-check for board outline. By doing this, you will be ensuring that you save a lot of communication time.

5.      What are composite layers in Gerber file?

Specific CAD software packages can split single copper layers into several Gerber files. Such a phenomenon is prevalent, especially for layers consisting of filled areas. The software can generate a separate file for traces, one for the copper pour, and a single for clearance.

The issue comes about due to a specific option that's within the CAD software. It would help if you were sure that you double-check all your files using a Gerber Viewer. That is before making your submission. If possible, you may have to ensure that you correct the settings of your CAD software.

6.      What is the importance of Gerber file for PCB?

As discussed earlier, PCB designs are getting complex, and the use of small components is required in complex and compact designs. Compact designs are constructed of multiple layers. The older vector photo plotters were only capable of tracing the single-layered design and component locations. PCB Gerber files are suitable for even more than 20 -layer PCBs. That is where Gerber files play an important role in the PCB manufacturing and fabrication industry. PCB Gerber files are suitable for multiple layered PCB designs as it traces layer by layer construction, along with the solder paste layers and component locations.

7.      Trying to solve drawing lines of Gerber file

A majority of manufacturers receive Gerber files that lack fabrication drawing with them. But what's the importance of a fab drawing? What's in a fabrication drawing? A fab drawing indicates a board's dimension. There are also important details, such as material type, file names, and thickness.

Any data that will help manufacturers to understand essential information about your board is helpful. But, when it comes to the submission of Gerber output files, most of them miss a fabrication drawing. If you want to ensure high-quality boards' production, you must ensure that you submit your Gerber output file plus the fabrication drawing together.
