The PCB manufacturing industry is always up against tough competition—and it has to follow strict rules too. On top of that, making PCBs involves a lot of different factors, and each one can change how much the final circuit board costs, all on its own.
PCB Instant Quote
In this passage, check and read the content below for more information about calculating PCB price.
To calculate PCB prices on PCBBUY’s instant quote page, follow these steps based on the parameters you select:
Size: Enter the PCB’s height (Y) and width (X) in mm.
Quantity: Specify the number of PCBs (e.g., 16 pieces as per your requirement).
Material: Choose from options like FR-4, FR-4 (Halogen-Free), FR-4 (Black core), or CEM-1.
Layers: Select the number of PCB layers (1, 2, 4, 6, 8, 10, or 12 layers).
Number of Designs: Indicate how many distinct PCB designs you need (1, 2, 3, 4, or custom).
Board Type: Choose between Single PCB, Panel by Customer (you provide panel layout), or Panel by PCBBUY (they create the panel).
Thickness: Select the PCB’s thickness (e.g., 0.3mm, 1.6mm, 3.0mm).
Finished Copper: Choose copper weight (1oz, 1.5oz, 2oz, 3oz) – this affects current-carrying capacity and cost.
Min Track/Spacing: Define the minimum trace width and spacing (e.g., 3/3mil, 8/8mil) – tighter tolerances increase cost.
Min Hole Size: Select the smallest via/hole diameter (e.g., 0.15mm, 0.4mm) – smaller holes require more precise drilling.
Solder Mask: Pick a color (Green, White, Black, etc.) – standard colors are cheaper; custom colors (e.g., Matte Green, Purple, Sakura pink) may cost more.
Silk Screen: Choose color (White, Black) or “None” – silk screen adds labeling but increases cost.
Surface Finish: Select from options like HASL Lead Free, ENIG, Immersion Tin, etc. – finishes like ENIG (gold) are more expensive than HASL.
Via Process: Choose how vias are treated (Tenting vias, Plugged vias, etc.) – plugged/epoxy-filled vias add cost.
Once all parameters are selected, the system automatically calculates the price based on PCBBUY’s pricing system, which factors in material costs, manufacturing complexity, quantity discounts, and process-specific expenses. The quote will update in real time as you adjust any parameter.
